5 - Operation
169
After the survey points have been collected, they
will be converted into a surface layer in which you
can define the color scheme Red, White, Blue, or
Brown-Tan. See “Legend Settings” on page 22.
You can select the number of legend ranges for
your field that will show the areas desired. This
theme will be used for each field until changed.
Hues will represent:
Red, white, blue scheme
Darker blue = Lower elevation.
Darker red = Higher elevations.
White will be a transition color between.
Brown-Tan scheme
Dark brown = Lower elevations.
Tan = Higher elevations.
If at any point during collection your GPS correction status changes out of RTK fixed, logging will be suspended.
If you re-acquire the RTK signal, logging will automatically resume.
At any point you can:
• Pause.
• Stop collection of the elevation survey.
• Resume as needed.
If you forget to stop logging as you leave the field, you will be prompted with the message that data collection is still active,
and be given the option to continue logging, or end operation.
÷
NOTE! In Odd-shaped fields, the surface
rendering of the elevation will connect
areas (A) even if you haven’t driven through
that area.
