4 - System setup
113
Guidance Options
Save
This allows you to save a pattern (.AGSETUP file) to
the displays internal memory.
Press and enter a unique pattern name.
When finished, press .
Pause
The Pause button allows your display to stop
logging points along an AB Line. Once this button
is pressed, a Resume button will take its place until
you press this button and Pause reappears.
÷
NOTE! If you are using the display to follow a set AB Line and wish to temporarily deviate from this line, you can use
the Pause button to pause the displays guidance logging activity. This feature could be used, for example, by a vehicle
operator who must refill a sprayer. When paused, the display will continue to give the distance back to the original
pause point position.
• Press button on the Guidance screen.
When you do so, the place where you paused appears on the Map screen as a yellow ball.
÷
NOTE! You can pause a pattern even if you have not set the “B” point yet. If you do so, the message in the lightbar will
read "Need B." If you pause the pattern after you have set your AB Line, then the lightbar will indicate the distance
your vehicle must travel to return to the pause point.
• Press button to resume your pattern and logging on your AB Line.
÷
NOTE! If you press the Resume button before you have returned to the original AB Line, your display will select the
closest AB Line to your vehicle.
Remark A
If you chose Straight patten, the Remark A button appears on the Guidance Options screen. The Remark A button "re-marks"
the A point by moving it to the current position while maintaining the same heading. A brief message appears in the on-
screen lightbar, stating "Point A Remarked."
Save Pattern
Enter New Description:
Show All Patterns
Name Swath Created Type
Group
Group
Curve
Smart
Smart
Smart
Straight
To Next Page
