Higen FDA5000 Series User Manual

Chapter 1. Checking and Handling
1-7
1.4 Order Specifications
Prior to installing the product, check the ratings plate to see if the related specifications match with
those of the order.
1.4.1 Servo motor model marking
1.4.2 Servo driver model marking
♦
Rated Power (Watt)
Symbol Rated Output (W) Symbol Rated Output (W)
01 100 15 1500
02 200 16 1600
03 300 20 2000
04 400 22 2200
05 450/500 30 3000
06 550/600 35 3500
07 650 40 4000
08 750/800 44 4400
09 850/900 50 5000
10 1000 55 5500
12 1200 75 7500
13 1300
♦ AC Servo Motor
♦
Series
Symbol Use
CN,CK High-speed, Low torque type
KF,KN Medium-speed, Standard type
TF,TN Medium-speed, High torque type
LF,LN Low-speed, High torque type
♦
Encoder Type
Symbol Pulse Type
A 2000
B 2500
C 3000
D 5000
E 6000
F 2048
G 2048 Absolute 11/13 bit
Incremental 15 line
FMA
♦
Shaft Type
Symbol Item
A Straight & No Key
B Straight & Key
C Tapper & Key
♦
Break Installed
Symbol Item
0 None
1 Oil seal attached
2 130 Flange ( Brake for 24V )
♦
Seal Type
Symbol Item
0 None
1 Oil seal attached
♦ AC Servo Drive
♦ Rated Power (Watt)
Symbol Power (W) Symbol Power (W) Symbol Power (W)
01 100 10 1000 30 3000
02 200 12 1200 45 4500
04 400 15 1500 75 7500
05 500 20 2000
50
FDA
♦
FDA5000 Series
♦ Encoder Type
Symbol Encoder Type
None Incremental
A Absolute
♦ Type
Symbol Encoder Type
None Standard type
M Standard type + M/Loader
C Position decision type
