Chapter 10. How to Use Speed/Position Servo
4
10-
10.4 How to Use Speed/Position Servo
To start speed/position servo, set the servo controller type to “3”.
10.4.1 Switching of control modes
Type ON OFF
ON Speed servo Position servo
(Caution!) Switch speed servo/position servo only when motor is stopped.
10.4.2 How to use by control mode
Refer to sections 7 and 8 for detailed directions by control mode.
Speed command for speed operation can be input freely by using 3 methods:
① Using 3 digital speed commands ([Speed CMD1 (P3-01)] - [Speed CMD3 (P3-03)]
② Using external analog speed command
③ Based on override operation by combining methods of items ① and ②
The internal speed command selection effected based on these 3 methods is decided as
follows based on CN1 speed selection ((SPD1), (SPD2)) contact and the [Override ON/OFF
(P3-18)] set values.
7[P3-18]
Speed
selection 2
Speed
selection 1
Speed command
0 OFF OFF Analog command sped
0 OFF ON [Speed CMD1 (P3-01)] speed
0 ON OFF [Speed CMD2 (P3-02)] speed
0 ON ON [Speed CMD3 (P3-03)] speed
1 OFF OFF Analog command sped
1 OFF ON
[Speed CMD1 (P3-01)] set speed + analog
command speed
1 ON OFF
[Speed CMD2 (P3-02)] set speed + analog
command speed
1 ON ON
[Speed CMD3 (P3-03)] set speed + analog
command speed
Where ON: Applicable contact is connected to "GND24".
OFF: Applicable contact is connected to "+24V", or applicable contact not connected.
