Network Video Recorder User Manual
73
7. Set the arming schedule. Refer to Configure Arming Schedule.
8. Set the linkage actions. Refer to Configure Linkage Actions.
9. Click Apply.
6.2.7 Unattended Baggage Detection
Unattended baggage detection detects the objects left over in a predefined region such as the
baggage, purses, dangerous materials, etc., and a series of actions can be taken when the alarm is
triggered.
Steps
1. Go to Smart Analysis → Smart Event Settings → Other Events.
2. Select a camera.
3. Click Unattended Baggage.
Figure 6-7 Unattended Baggage Detection
4. Check Enable Unattended Baggage Detection.
5. Optional: Check Save VCA Picture to save the captured unattended baggage detection pictures.
6. Set the detection rules and detection areas.
1) Select Arming Area.
Note
Up to 4 areas are selectable.
2) Drag the sliders to set Time Threshold and Sensitivity.
