Storing, Logging and Printing
Recalling Stored Graph Results
Recalling Stored Graph Results
Description Results stored from a previous measurement can be recalled to the
graphics displays for viewing and printing.
HOW TO: 1 If currently viewing the bar graph display, select then
. If currently viewing the error or alarm summary,
select .
2 Using and , move the highlighted cursor to the store location
which contains the required results.
If the required results are stored on Disk, move the highlighted cursor
to DISK and choose RECALL GRAPHICS on the FLOPPY DISK
display. See “Recalling Graphics Results from Disk” page 149.
3 Choose if you wish to view the bar graphs.
The display will change to the bar graph display of the highlighted
results.
4 Choose if you wish to view the error and alarm
Summaries.
The display will change to the text results display of the highlighted
results.
deletes the results in the highlighted store.
TEXT RESULTS
STORE STATUS
STORE STATUS
GRAPH RESULTS
TEXT RESULTS
DELETE STORE
