84
Making Measurements
Making SONET Analysis Measurements
Making SONET Analysis Measurements
Description G.826 analysis results are provided for all relevant SDH/SONET error
sources.
In addition the following results are provided:
Cumulative error count and error ratio
Short Term error count and error ratio
Alarm Seconds
Pointer Values
Frequency
HOW TO: 1 Set up the SONET transmit interface and payload required.
2 Set up the SONET receive interface and payload as required.
3 Press to start the measurement.
4 You can view the analysis results on the
display.
TIP: The measurement will not be affected if you switch between the different
results provided.
RUN/STOP
RESULTS
SONET ANALYSIS
