HP 83751A User Manual

I
-
I
-
Specifications and Options
RF Output
Power Sweep
f25 dB/sweep, maximum
Usable from minimum to maximum leveled power, within any one
attenuator setting.
Settable to f35 dB/sweep.
Power Slope
0 to f2 dB/GHz, up to power sweep limit
External Leveling
External detector:
range:
-0.2 mV to -0.5 V
bandwidth (sweep speed and modulation mode dependent): 10 or 100
kHz, nominal
Etiernal power meter: 1 Hz bandwidth, nominal
External mm-wave module: HP 83550 series compatible with Option 1EE
User Flatness (Level) Correction
Number of points: 2 to 801 points/table
Number of tables: up to 9
Entry modes: power meter, HP-IB (Compatible with HP 437B, 438A,
70100, and SCPI compatible power meters)
17-9
