Specifications and Options
General
Power
Requirements
90-132 VAC (47-66 Hz), 103.5-126.5 VAC (380-420 Hz), or 198-250 VAC
(47-66 Hz); 400 VA maximum (standby 100 VA). Optimum voltage range
automatically selected.
If this instrument is to be energized via an external autotransformer for
voltage reduction, make sure that its common terminal is connected to a
neutral (earthed pole) of the power supply.
Dimensions
133 mm high by 425 mm wide by 498 mm deep (5.25 in. high by 16.75 in.
wide by 19.6 in. deep); excluding front and rear panel protrusions.
j_
498
_I
I
I
SIDE VIEW
I
pg432ab
Figure 17-4. Dimensions
17-17
