HP 83751A User Manual

I
-
Modulation
Please note that all modulation characteristics are typical or nominal, and are
not warranted parameters.
Pulse
On/Oflratio: 60 dB
RisePaLL times:
0.5 to 2 GHz: 15 ns
2 to 20 GHz: 100 ns rise, 50 ns fall
Minimum Leveled width: 2 ps @or frequencies > 500 MHz in CW mode, or
> 2 GHz in swept mode.)
Internal pulse generator:
Width range: 1 ,LAS to 65 ms
Period range: 2 ps to 65 ms
Resolution: 1 ps
Internal square wave: 1 .O kHz and 27.8 kHz (scalar mode)
AM
Sensitivity: 1 dB/V
Bandwidth (3 dB): > 100 kHz, usable to 1 MHz
Depth for HP 8375X& 20 dB; (+ 10 dBm to -10 dBm)
Depth for HP 8375XB: 22 dB; (i- 17 dBm to -5 dBm)
Input impedance: 3.5 kohms
17-13
