Front/Rear Panel
Connectors
RF
Output
Connector
The standard front panel RF OUTPUT connector is a precision 3.5 mm male
connector. When Option
1ED
is installed, this front panel connector is a
ruggedized Type-N connector. The nominal source impedance is 50
61.
When making connections to this connector, carefully align the center
conductor elements, then rotate the knurled barrel while mating components
remain still. Tighten the barrel until Iirm contact is made.
lkke
care when working with this connector. If the connector is mechanically
degraded in any way, high frequency losses can occur. Refer to application
note 326, Coaxial
Sz/stems
-
Principles of Microwave Connector Care
(HP
part
number
5954-
1566) for more information.
7-15
-1
