PERFORMANCE TESTS
MODEL
8559A
TABLE
4
-
18.
PERFORMANCE TEST RECORD
(3
OF
4)
Para.
No.
Test Description
Residual Responses
6. Residual Responses, .Ol GHz to 3 GHz
7.
Residual Responses, .Ol GHz to 3 GHz
(ALT
IF)
Frequency Response
15. Frequency Response,
.Ol
to 3.0 GHz
18. Frequency Response, 6.0 to 9.0 GHz
20. Frequency Response, 3.0 to 9.0 GHz
22. Frequency Response, 9.0 to 15.0 GHz
24. Frequency Response, 6.0 to 15.0 GHz
26. Frequency Response, 12.1 to 18.0 GHz
32. Frequency Response, 18.0 to 21.0 GHz
Gain Compression
1
1.
Gain Compression
Bandwidth Switching (Amplitude Variation)
6.
3 MHz to 300 kHz (overall variation)
3 MHz to 1 kHz (overall variation)
Input Attenuator Accuracy
5.
Maximum Error per 10
-
dB step
(0 dB
-
60 dB)
6.
Maximum Cumulative Step Error
(0 dB
-
60 dB)
Reference Level Variation
4.
Reference Level Error in
Log
(
-
10 dBm to
-
80 dBm)
Reference Level Error in
Log
(
-
10 dBm to
-
100 dBm)
8. Reference Level Error in LIN
(
-
10 dBm to
-
80 dBm)
Reference Level Error in LIN
(
-
10 dBm to
-
100 dBm)
1
1. Vernier Error
Min.
Results
Actual
Max.
To Next Page
