HP 8559A User Manual

MODEL 8559A
GENERAL INFORMATION
TABLE
1 - 1.
HP MODEL 8559A SPECIFICATIONS (3 OF 4)
Display Fidelity
CRT linearity and log or linear fidelity affect
amplitude accuracy at levels other than Refer
-
ence Level.
Log Incremental Accuracy:
+ 0.1 dB per dB from Reference Level
Log Maximum Cumulative Error:
I + 1.5 dB over entire 70 - dB range
Linear Accuracy:
+ 3% of Reference Level
RESIDUAL RESPONSES
< -90dBm (0.01 - 3.06 GHZ)~ with 0 dB input
attenuation and no signal present at input.
SWEEP SPECIFICATIONS
SWEEP TIME
Automatic (AUTO):
Sweep time adjusted automatically to maintain
absolute amplitude calibration for any combina
-
tion of frequency span, resolution bandwidth,
and video filter bandwidth.
Calibrated Sweep Times (sec/Div, mSec/Div,
rSeclDiv):
20 selectable sweep times in 1 - 2 - 5 sequence from
2
psec/div to 10 sec/div (excluding 2 sec/div),
provided primarily for time - domain calibration
in zero span
(0).
Sweep time accuracy: r 10% (+20% for 5
and 10
sec/div)
GENERAL SPECIFICATIONS
TEMPERATURE RANGE
Operating: 0°C to + 55°C
Storage:
- 40°C to + 75°C
HUMIDITY RANGE
Type - tested from 50% to 95% relative humidity
( I + 40°C) per requirements of MIL - STD - 8 10C,
Method 507.1, Procedure I1
'0.025 - 3.06 GHz with ALT IF selected.
EM1
Conducted and radiated interference is in com -
pliance with MIL - STD 461A, Methods CEO3
and RE02, CISPR Publication 11 (1975) and
Messempfaenger Postverfuegung
526/527/79
(Kennzeichnung Mit F-Nummer/Funkschutzzei-
chen).
POWER REQUIREMENTS
HP Model 853A Display with HP Model
8559A
Spectrum Analyzer:
100 or 120 Vac + 5% - lo%, 48 to 66 Hz, single-
phase. Power consumption less than 200 Volt-
amperes with plug - in installed.
HP Model 182T/180TR Display with HP Model
8559A Spectrum Analyzer:
11 5 or 230 Vac + lo%, 48 - 440 Hz. Power con -
sumption less than 200 Volt - amperes with plug -
in installed, convection cooled.
HP Model 181T/181TR Display with HP Model
8559A Spectrum Analyzer:
115 or 230 Vac + lo%, 48 - 440 Hz. Power con -
sumption less than 225 Volt - amperes with plug -
in installed, convection cooled.
WEIGHT
HP Model
8559A Spectrum Analyzer:
Net: 5.5 kg (12.1 lbs)
Shipping: 9.1 kg (20 lbs)
HP Model 853A Display:
Net: 15.9 kg (35 lbs)
Shipping: 18.6 kg (41 lbs)
HP Model 853A Option 001 Display:
Net: 14.5 kg (32 lbs)
Shipping: 17.3 kg (38 lbs)
HP Model 182T Display:
Net: 12.5 kg (27 lbs)
Shipping: 16.5 kg (36 lbs)
HP Model 181T Display:
Net: 11.0 kg (24 lbs)
Shipping: 15.5 kg (34 lbs)
HP Model 181TR Display:
Net: 12.0 kg (26 lbs)
Shipping: 17.5 kg (38
lbs)
HP Model 180TR Display:
Net: 12.0 kg (26 lbs)
Shipping: 17.5 kg (38 lbs)
