MODEL 8559A
TABLE
1-4.
RECOMMENDEDTEST EQUIPMENT(2 OF4)
GENERAL INFORMATION
Critical Specifications
Frequency: 500 Hz
Display Amplitude
:
-
1 5 Vdc
Single
-
Channel
Frequency Range
:
20 MHz to 23 GHz
Sensitivity:
-
1 5 dBm
Resolution: 0.1 MHz
Time Interval Measurement from 1 ms to 500 ms
Range:
-
12 to +I5 Vdc
Accuracy: +I mV
Range
:
-
20 to
+
10
dBm
Resolution: 0.1 dB
Frequency Range: 50 MHz to 26.5
GHz
Maximum SWR:
1
.15, 50 MHz to 100 MHz
1.10,lOO MHz to 2 GHz
1.15,2 to 12.4 GHz
1.20, 12.4 to 18 GHz
1.25, 18 to 26.5 GHz
Frequency Range
:
10 MHz to 18 GHz
Maximum SWR:
1.40,10 MHz to 30 MHz
1
.l8,3O MHz to 50 MHz
1
.lo,
50 MHz to
2
GHz
1.18,2 to
12.4GHz
1.28, 12.4 to 18 GHz
Frequency Range: 10 MHz to 18 GHz
Tracking between output arms: G0.25 dB
Connectors:
Type
N
(0
input, Type
N
(m)
outputs
Frequency Range: 20 MHz to 350 MHz
Attenuation Range:
0 to 90 dB in 10 dB steps
Step Accuracy:
kO.l
dB
Overall Accuracy
(0 to 90 dB): k0.2 dB
Frequency Range: 20 MHz to 350 MHz
Attenuation Range:
0 to 12 dB in 1 dB steps
Step Accuracy: k0.05 dB
Overall Accuracy
(0 to 12 dB): kO.l dB
Recommended
Model
Use
"
instrument
Oscilloscope
Frequency
Count~r
Universal Counter
Digital Voltmeter
Power Meter
Power Sensor
Power Sensor
Power Splitter
Step Attenuator
Step Attenuator
*P
=
Performance Test;
Option C16 provides
A
=
Adjustments;
T
=
Troubleshooting
Type
N
(m) output connectors to eliminate the use of adapters.
4~ption H82 is selected for best attenuation accuracy and provides calibration data at 30
MHz
and 280 MHz.
Option H80 is selected for best attenuation accuracy and provides calibration data at
100
MHz.
