MODEL 8559A GENERAL INFORMATION
TABLE
1-2.
MODEL 8559N180SERIES SUPPLEMENTAL CHARACTERISTICS (3OF 3)
SUPPLEMENTAL CHARACTERISTICS
NOTE: Values in this table are not specifications. They are typical characteristics
included for user information.
AUX C 21.4 MHz IF OUTPUT
BNC output provides 21.4 MHz IF signal (lin -
early related to spectrum analyzer RF input)
from a
50-ohm output impedance. Output band -
width controlled by spectrum analyzer RESO -
LUTION BW setting; output amplitude con -
trolled by INPUT ATTEN, REFERENCE
LEVEL FINE, and first six REFERENCE
LEVEL positions
(i.e., - 10 through - 60 dBm
with 0 dB input attenuation). Output level is
approximately
- 10 dBm into 50 ohms with a
signal displayed at Reference Level.
AUX D HORIZONTAL OUTPUT
BNC output provides horizontal sweep voltage
from a
SK - ohm output impedance. - 5V to
+ SV range corresponds to h11 10 - division CRT
horizontal deflection.
