MODEL 8559A ADJUSTMENTS
ADJUSTMENTS
5 - 25. FIRST CONVERTER ADJUSTMENTS (Cont'd)
First LO Adjustments
2. Connect DVM to A7TP6 TUNE.
3. Set spectrum analyzer controls as follows:
INPUT
ATTEN .............................................................. 0 dB
FREQ
SPAN/DIV ............................................................... 0
ALTIF ..................................................................... OFF
4.
Connect frequency counter to spectrum analyzer
RF Input.
5.
Jumper
A16TPl DIODE BIAS to ground. A16TP1 is located on the motherboard through a hole in the
analyzer left side gusset.
6. Adjust front
- panel TUNING control for DVM indication of 0.000 Vdc (fully counterclockwise).
7. Adjust
A7R8 (3 GHz) for frequency counter indication of 3.000 GHz + 1 MHz. (If this adjustment cannot
be achieved, factory select resistor
A7R3* can be added - if it is not installed - or decreased to provide the
proper range. Select a value of 147K ohms for
A7R3*, initially, and decrease this value to no less than
56.2K ohms.)
8. Adjust front
- panel TUNING control for DVM indication of - 10.000 Vdc.
9. Set A7R75 6 GHz F (fine) to approximately mid - range (R75 is a 20-turn potentiometer).
10. Adjust
A7R47 6 GHz C (coarse) for a frequency counter indication of 6.000 GHz +2 MHz.
11. Retune front
- panel TUNING control for 0.000 Vdc DVM indication and readjust A7R8 3 GHz if neces -
sary for frequency counter indication of 3.000 GHz * 1 MHz.
12.
The front - panel TUNING control for - 10.000 Vdc DVM indication.
13. Lightly tap the top edge of the A7 Frequency Control board with the handle of
a small screwdriver to seat
controls.
14. Adjust
A7R75 6 GHz F (fine) for frequency counter indication of 6.000 GHz * 1 MHz.
