HP A5800 Series Installation Guide

105
LED
Availability
Management Ethernet port LEDs
A5800AF-48G, A5800-24G-SFP (1 slot), A5800-24G-SFP TAA (1 slot)
A5820AF-24XG, A5820X-24XG-SFP+, A5820X-24XG-SFP+ TAA
OAP card status LED
A5800-48G-PoE+ (2 slots), A5800-48G-PoE+ TAA (2 slots)
A5820X-14XG-SFP+ (2 slots), A5820X-14XG-SFP+ TAA (2 slots)
PoE module status LED
A5800-48G-PoE+ (2 slots), A5800-48G-PoE+ TAA (2 slots)
Interface card status LED
A5800 series but the following models:
A5800-48G-PoE+ (2 slots), A5800-48G-PoE+ TAA (2 slots), A5800AF-
48G, A5800-24G-SFP (1 slot), A5800-24G-SFP TAA (1 slot)
System status LED
The system status LED shows the operating status of the switch.
Table 25 System status LED description
LED mark
Status
Description
SYS
Steady green
The switch is operating properly.
Flashing green (1 Hz)
The switch is performing power-on self test (POST).
Steady red
POST has failed.
Flashing yellow (1 Hz)
Some ports have failed to pass POST.
Off
The switch is powered off.
Power supply status LED
A power supply status LED shows how the hot swappable power supply in a slot is operating.
Table 26 Power supply status LED description
LED mark
Status
Description
PWR1
Steady green
A power supply is installed in power supply slot 1, and the
power output is normal.
Steady yellow
A power supply is installed in power supply slot 1, but the power
supply has an output problem.
Off
No power supply is installed in power supply slot 1, or no
power is being input.
PWR2
Steady green
A power supply is installed in power supply slot 2, and the
power output is normal.
Steady yellow
A power supply is installed in power supply slot 2, but the power
supply has an input problem.
Off
No power supply is installed in power supply slot 2, or no
power is input.
