110
OAP card status LED
The SLOT3 LED on the front chassis panel shows the status of the card in the OAP card slot.
Table 36 OAP card status LED description
An OAP card is in the slot and operating properly.
The slot does not support the OAP card model, or the OAP
card has failed.
The OAP card slot is empty.
PoE module status LED
The SLOT4 LED shows the status of the PoE module.
Table 37 PoE module status LED description
The PoE module is in position and operating properly.
The switch does not support the PoE module model, or the
PoE module has failed.
The PoE module slot is empty.
Interface card status LED
The SLOT1 LED shows the status of the interface card or the OAP card in the expansion interface card
slot.
Table 38 Interface card status LED description
The interface card or the OAP card is in position and
operating properly.
The slot does not support the card model, or the card has
failed.
The expansion interface card slot is empty.
