452 XML API basetype properties
replication-volume
Properties
Table 63 replication-volume properties
Name Type Description
name string Replication volume name.
serial-number string Replication volume serial number.
status string Replication volume status.
• Initializing: The initial (full) replication to the volume is in progress.
• Online: The volume is online and is consistent with the last replicated
image.
• Inconsistent: The volume is online but is in an inconsistent state. A full
replication is required to initialize it.
• Replicating: The volume is online and replication is in progress.
• Replicate-delay: The volume is online but the in-progress replication
has been temporarily delayed; a retry is occurring.
• Suspended: The volume is online but the in-progress replication has been
suspended.
• Offline: The volume can be accessed but is unusable due to an error.
• Establishing proxy: The volume is establishing a proxy connection to
a remote volume. This will occur when a detached secondary volume is
reattached and is re-establishing a connection with the primary system in
preparation for replication.
• Detached: The volume is detached for removal.
status-numeric string Numeric equivalents for status values.
• 0: Initializing
• 1: Online
• 2: Inconsistent
• 3: Replicating
• 4: Replicate-Delay
• 5: Suspended
• 6: Offline
• 7: Establishing proxy
• 8: Detached
status-reason string More information about the status value.
• N/A
• Record Missing
• Adding Volume
• Changing Primary
status-reason-
numeric
string Numeric equivalents for status-reason values.
• 0: N/A
• 1: Record Missing
• 2: Adding Volume
• 4: Changing Primary
monitor string Replication volume monitoring status.
• OK: Communication to the remote volume is successfully occurring on the
network.
• Failed: Communication to the remote volume has failed because of a
communication issue or because the remote volume has gone offline.
