HP P2000 G3 MSA System CLI Reference Guide 459
sas-status-controller-a
Properties
Table 67 sas-status-controller-a properties
Name Type Description
enclosure-id uint32 Enclosure ID.
controller string • A: Controller A.
• B: Controller B.
controller-
numeric
string Numeric equivalents for controller values.
• 0: B
• 1: A
phy uint32 Logical ID of the PHY within a group based on the PHY type.
• Drive PHYs have IDs 0–23.
• SC (Storage Controller) PHYs have IDs 0–1.
• Egress, ingress, and inter-expander PHYs have IDs 0–3.
type string PHY type.
• Undefined: The PHY doesn't exist in the expander.
• Drive: 1-lane PHY that communicates between the expander and a disk
drive.
• Ingress: (Expansion module only) 4-lane PHY that communicates between
the expander and an expansion port.
• Egress: 4-lane PHY that communicates between the expander and an
expansion port or SAS Out port.
• Inter-Exp: (Expansion module only) Communicates between the
expander and the partner's expander.
• SC-0: (Controller module only) 4-lane PHY that communicates between the
expander and the SC.
• SC-1: (Controller module only) 2-lane PHY that communicates between the
expander and the partner's expander.
• Unused: The PHY exists in the expander but is not connected, by design.
type-numeric string Numeric equivalents for type values.
• 0: Undefined
• 1: Drive
• 2: Ingress
• 3: Egress
• 4: Inter-Exp
• 6: Unused
• 50: SC-0
• 51: SC-1
status string PHY status.
• Unavailable: No status information is available.
• Enabled - Healthy: The PHY is enabled and healthy.
• Enabled - Degraded: The PHY is enabled but degraded.
• Disabled: The PHY has been disabled by a user or by the system.
status-numeric string Numeric equivalents for status values.
• 0: Unavailable
• 1: Enabled - Healthy
• 2: Enabled - Degraded
• 3: Disabled
