e. Click OK.
f. In the information list, right-click the record and choose Download to NE from
the shortcut menu.
g. In the dialog box that is displayed, select the required NE(s), and click OK.
3. Configure a line profile.
In a line profile, a GEM port can be bound to up to eight service streams. In a GEM
port, different GEM connections need to be set up for different service streams.
In this example, the mapping between GEM ports and MDU-side services is
implemented through VLANs, and the service streams of each service are mapped to
GEM port 1. In addition, different GEM connections are set up for the management
VLAN and the VLANs for the Internet, voice, and multicast services.
a. Choose Configuration > Access Profile Management from the main menu. In
the dialog box that is displayed, choose PON Profile > GPON Profile from the
navigation tree.
b. Click the Line Profile tab.
c. Right-click and choose Add Global Profile from the shortcut menu.
d. In the dialog box that is displayed, set the parameters.
– Set Name to FTTx.
– Choose Base Info. from the navigation tree and set the parameters.
– Mapping Mode: VLAN
– Qos Mode: Priority Queue
EchoLife HG8010/HG8110/HG8240/HG8245/HG8247/
HG8447 GPON Terminal
Service Manual 3 Configuration
Issue 02 (2011-12-08) Huawei Proprietary and Confidential
Copyright © Huawei Technologies Co., Ltd.
97
