3.5.1 Preparations
Before configuring services on the U2560, plan data of the entire network in a unified manner
and add the ONT to the U2560.
Commissioning Interoperation Between the U2560 and the ONT Through the Web
Page
To configure and issue ONT services using the U2560, you need to add the ONT on the U2560
so that the U2560 can manage the ONT.
Prerequisite
Before adding an ONT to the U2560, ensure that Layer 2 service channels between the OLT and
the ONT are enabled and the management traffic stream on the U2560 are created. For details,
see Enabling Layer 2 Service Channels Between an OLT and a GPON ONT (on the OLT
CLI).
Data Plan
Table 3-14 provides the data plan for commissioning interoperation between the U2560 and the
ONT through the Web page.
Table 3-14 Data plan for commissioning interoperation between the U2560 and the ONT
through the Web page
Parameter
Data Description
Service type of
the WAN
interface
TR069 When configuring the U2560 management channel,
you need to select only TR069 or a combination with
TR069. In this example, TR069 is selected.
Connection
mode
Route -
VLAN ID of the
WAN interface
50 The VLAN ID of the WAN interface must be the
same as the CVLAN ID configured on the OLT.
Mode of
obtaining an IP
address
DHCP There are three modes to obtain an IP address:
l DHCP: Obtain an IP address dynamically.
l Static: Configure an IP address manually.
l PPPoE: Access in the PPPoE dialup mode.
In this example, the DHCP mode is configured. You
can also select the static or PPPoE mode according
to the data plan of the upper-layer network.
ACS URL
http://
10.11.11.1:9070
It can be the IP address, port ID, domain name of the
ACS server.
Periodical
notification
interval
43200 It is the default value of the system.
EchoLife HG8010/HG8110/HG8240/HG8245/HG8247/
HG8447 GPON Terminal
Service Manual 3 Configuration
Issue 02 (2011-12-08) Huawei Proprietary and Confidential
Copyright © Huawei Technologies Co., Ltd.
235
