Product Number of
ETH Ports
Number of
POTS Ports
Number of
CATV Ports
HG8010 1 - -
HG8110 1 1 -
HG8240 4 2 -
HG8245 4 2 -
HG8247 4 2 1
HG8447 4 4 1
a. Choose Configuration > Access Profile Management from the main menu. In
the dialog box that is displayed, choose PON Profile > GPON Profile from the
navigation tree.
b. Click the Service Profile tab.
c. Right-click and choose Add Global Profile from the shortcut menu.
d. In the dialog box that is displayed, set the parameters.
– Set Name to FTTx.
– Choose Base Info. from the navigation tree and set the parameters.
– Number of Pots Ports: 2
– Number of ETH Ports: 4
– Number of CATV Ports: 1
e. Click OK.
f. In the information list, right-click the record and choose Download to NE from
the shortcut menu.
g. In the dialog box that is displayed, select the required NE(s), and click OK.
5. Confirm the ONT.
EchoLife HG8010/HG8110/HG8240/HG8245/HG8247/
HG8447 GPON Terminal
Service Manual 3 Configuration
Issue 02 (2011-12-08) Huawei Proprietary and Confidential
Copyright © Huawei Technologies Co., Ltd.
69
