Configuration File
vlan 100 smart
vlan attrib 100 stacking
port vlan 100 0/19 0
dba-profile add profile-id 10 type4 max 102400
ont-lineprofile gpon profile-id 10
tcont 4 dba-profile-id 10
gem add 1 eth tcont 4
mapping-mode vlan
gem mapping 1 0 vlan 10
commit
quit
ont-srvprofile gpon profile-id 10
ont-port eth 4 pots 2 catv 1
commit
quit
interface gpon 0/1
port 1 ont-auto-find enable
display ont autofind 1
ont confirm 1 ontid 1 sn-auth 6877687714852900 omci ont-lineprofile-id 10 ont-
srvprofile-id 10ont confirm 1 ontid 2 sn-auth 6877687714852901 omci ont-lineprofile-
id 10 ont-srvprofile-id 10ont alarm-profile 1 1 profile-id 1
ont alarm-profile 1 2 profile-id 1
quit
traffic table ip index 8 cir 4096 priority 1 priority-policy tag-In-Package
service-port 1 vlan 100 gpon 0/1/1 ont 1 gemport 1 multi-service user-vlan 10 rx-
cttr 8 tx-cttr 8
service-port 2 vlan 100 gpon 0/1/1 ont 2 gemport 1 multi-service user-vlan 10 rx-
cttr 8 tx-cttr 8
queue-scheduler wrr 10 10 20 20 40 0 0 0
cos-queue-map cos0 0 cos1 1 cos2 2 cos3 3 cos4 4 cos5 5 cos6 6 cos7 7
save
3.3.4 Configuring the GPON FTTH VoIP Service (H.248 Protocol)
on the OLT CLI
The OLT is connected to the remote ONT through a GPON port to provide users with the IP-
based high-quality and low-cost VoIP service.
Service Requirements
l The ONT is connected to the MGC through H.248.
l The ONT obtains the IP address through DHCP.
l Two phone sets are connected to two TEL ports of the ONT respectively, and calls can be
made between two phone sets.
l Users of phone sets under different ONTs can call and communicate with each other.
l The DBA mode of the VoIP service is assured bandwidth + maximum bandwidth, and no
rate limitation is performed on the upstream and downstream traffic.
Table 3-7 Data plan
Item
Data
OLT S-VLAN ID: 200
S-VLAN type: smart VLAN
Upstream port: 0/19/0
C-VLAN ID: 20
EchoLife HG8010/HG8110/HG8240/HG8245/HG8247/
HG8447 GPON Terminal
Service Manual 3 Configuration
Issue 02 (2011-12-08) Huawei Proprietary and Confidential
Copyright © Huawei Technologies Co., Ltd.
151
