Parameter Description
User Name Indicates the user name for connecting to the FTP server. If the
FTP server supports anonymous login, the setting is not required.
Password Indicates the password for connecting to the FTP server. If the
FTP server supports anonymous login, the setting is not required.
Device Indicates the drive of the external USB device for saving the file
downloaded through FTP. When the USB storage device is
connected to the USB port, the drop-down list is available.
Local Path Indicates the path for saving the FTP-downloaded file to the
external USB device. If the path is not entered, the path specified
in Download URL is used by default.
5.8.2 ALG Configuration
1. In the navigation tree on the left, choose Network Applications > ALG Configuration.
In the pane on the right, determine whether to enable the FTP or TFTP, as shown in Figure
5-29.
Figure 5-29 ALG Configuration
2. Click Apply to apply the configuration.
When the NAT function is enabled, the application level gateway (ALG) function needs to be
enabled to ensure that some application software and hardware can be normally used.
5.8.3 UPnP Configuration
1. In the navigation tree on the left, choose Network Applications > UPnP Configuration.
In the pane on the right, determine whether to enable the UPnP, as shown in Figure 5-30.
EchoLife HG8010/HG8110/HG8240/HG8245/HG8247/
HG8447 GPON Terminal
Service Manual 5 Web Page Reference
Issue 02 (2011-12-08) Huawei Proprietary and Confidential
Copyright © Huawei Technologies Co., Ltd.
329
