– Service Type: Translation
– S-VLAN: 10 (Internet access user-side VLAN ID)
– C-VLAN: 10 (Internet access user-side VLAN ID)
– Choose UNI Port from the navigation tree. In the window that is displayed,
right-click the record where Port Type is set to ETH and Port ID is set to
3, and choose UNI Port Configuration Properties from the shortcut menu.
In the dialog box that is displayed, set the parameters.
– In the dialog box that is displayed, right-click and choose Add, and
configure the parameters of VLAN switch.
– Service Type: Translation
– S-VLAN: 30 (Multicast user-side VLAN ID)
– C-VLAN: 30 (Multicast user-side VLAN ID)
e. Click OK.
f. In the information list, right-click the record and choose Download to NE from
the shortcut menu.
g. In the dialog box that is displayed, select the required NE(s), and click OK.
5. Confirm the ONT.
EchoLife HG8010/HG8110/HG8240/HG8245/HG8247/
HG8447 GPON Terminal
Service Manual 3 Configuration
Issue 02 (2011-12-08) Huawei Proprietary and Confidential
Copyright © Huawei Technologies Co., Ltd.
102
