CAUTION
l Web interface and the U2000 cannot use the same XML configuration file. The XML
configuration file of Web interface contains all configuration data, while the XML
configuration file of the U2000 contains only part of the configuration data.
l H.248 and SIP can share the same XML configuration file, but the configurations involving
voice service need to be re-configured accordingly.
l The XML configuration file is generally exported for modifying, and then imported back.
Configuration rolls back or even factory defaults are restored if an incorrect XML
configuration file is imported. When configuration parameters of an XML configuration file
need to be modified, please contact Huawei technical engineers for help.
3.6.1 Operation Guide on the XML Configuration File (on the Web
Page)
This topic describes how to issue the XML configuration file on the Web page.
Prerequisite
You have established the environment for logging in to the Web page for service configuration
and have successfully logged in to the Web page. For details, see 3.4.3 Locally Logging in to
the Web Interface.
Procedure
Step 1 Export the XML configuration file.
1. In the navigation tree, choose System Tools > Configuration File.
2. In the details area, click Download Configuration File, as shown in the following figure.
Figure 3-10 Exporting the XML configuration file
3. In the dialog box that is displayed, click Save to save the XML configuration file.
EchoLife HG8010/HG8110/HG8240/HG8245/HG8247/
HG8447 GPON Terminal
Service Manual 3 Configuration
Issue 02 (2011-12-08) Huawei Proprietary and Confidential
Copyright © Huawei Technologies Co., Ltd.
265
