cttr 10
tx-cttr 10
queue-scheduler wrr 10 10 20 20 40 0 0 0
cos-queue-map cos0 0 cos1 1 cos2 2 cos3 3 cos4 4 cos5 5 cos6 6 cos7 7
multicast-vlan 1000
igmp mode proxy
igmp version v3
igmp uplink-port 0/19/0
btv
igmp uplink-port-mode default
multicast-vlan 1000
igmp program add name program1 ip 224.1.1.10 sourceip 10.10.10.10
btv
igmp profile add profile-name profile0
igmp profile profile-name profile0 program-name program1 watch
igmp policy service-port 5 normal
igmp policy service-port 6 normal
igmp user add service-port 5 auth
igmp user add service-port 6 auth
igmp user bind-profile service-port 5 profile-name profile0
igmp user bind-profile service-port 6 profile-name profile0
multicast-vlan 1000
igmp multicast-vlan member service-port 5
igmp multicast-vlan member service-port 6
quit
save
3.3.7 Configuring the GPON FTTH Layer 3 Bridge Multicast Service
on the OLT CLI
The OLT is connected to the remote ONT through a GPON port to provide users with the IPTV
service.
Service Requirements
l The ONT is connected to the OLT in the Layer 3 bridge mode.
l The ONT adopts IGMP Snooping multicast protocol.
l The OLT adopts IGMP proxy multicast protocol.
l Multicast programs are configured statically and multicast users are authenticated.
l The IGMP version of the multicast VLAN is IGMP V3.
l The user accesses the device through GPON, and has the right to order programs from the
multicast source.
Table 3-10 Data plan
Item
Data
OLT Service VLAN ID: 1000
Service VLAN type: smart VLAN
Upstream port: 0/19/0
Multicast protocol: IGMP Proxy
Multicast version: IGMP V3
IP address of the multicast server: 10.10.10.10
Multicast program: 224.1.1.10
EchoLife HG8010/HG8110/HG8240/HG8245/HG8247/
HG8447 GPON Terminal
Service Manual 3 Configuration
Issue 02 (2011-12-08) Huawei Proprietary and Confidential
Copyright © Huawei Technologies Co., Ltd.
190
