l Click Download Configuration File. In the dialog box that is displayed, click Save, specify
the path of saving the configuration file, and then back up the file to the local disk.
l Click Browse following the Configuration File text box. In the dialog box that is displayed,
select the configuration file to be uploaded. Click Upload Configuration File to upload
the configuration file that is saved in the local disk. After the configuration file is
successfully uploaded, the device automatically restarts and then the new configuration
takes effect.
CAUTION
Before uploading the configuration file, choose the configuration file with the correct type
and the name of the selected configuration file must not be the same as that of any file saved
in the device. Otherwise, the configuration file fails to be uploaded.
5.10.3 USB Backup Restore CFG
Click the System Tools tab and then choose USB Backup Restore CFG from the navigation
tree. In the pane on the right, the button as required, as shown in Figure 5-45.
Figure 5-45 USB Backup Restore CFG
l Select Enable restore from USB to configure whether the system supports fast recovery
of the backed up configured file from the USB storage device.
l Click Backup configuration to back up the configuration file to the specified USB storage
device.
CAUTION
After the configuration file in the USB storage device is successfully uploaded, the device is
restarted and then the new configuration data takes effect.
5.10.4 Firmware Upgrade
1. In the navigation tree on the left, choose System Tools > Firmware Upgrade. In the pane
on the right, click Browse. In the dialog box that is displayed, select the target software
EchoLife HG8010/HG8110/HG8240/HG8245/HG8247/
HG8447 GPON Terminal
Service Manual 5 Web Page Reference
Issue 02 (2011-12-08) Huawei Proprietary and Confidential
Copyright © Huawei Technologies Co., Ltd.
344
