CAUTION
If the LAN-side device does not provide website service or other network services, do not set
the device to a DMZ host because all ports of a DMZ host are opened to the Internet.
Table 5-9 describes the parameters related to the DMZ.
Table 5-9 Parameters related to the DMZ
Parameter Description
Interface Name Indicates the name of the WAN interface. If the WAN interface
is not in the port mapping table, the application requests from
the WAN connection are directly forwarded to the host in the
DMZ.
Host Address Indicates the IP address of the DMZ host.
Enable DMZ Indicates whether to enable the DMZ.
5.7.2 PortMapping Configuration
1. In the navigation tree on the left, choose Forward Rules > PortMapping
Configuration. In the pane on the right, click New. In the dialog box that is displayed, set
the parameters related to port mapping, as shown in Figure 5-26.
Figure 5-26 PortMapping Configuration
2. Click Apply to apply the configuration.
Port mapping indicates that the Intranet server is allowed to be open to the Extranet (for example,
the Intranet provides the Extranet with a WWW server or FTP server). Port mapping is to map
EchoLife HG8010/HG8110/HG8240/HG8245/HG8247/
HG8447 GPON Terminal
Service Manual 5 Web Page Reference
Issue 02 (2011-12-08) Huawei Proprietary and Confidential
Copyright © Huawei Technologies Co., Ltd.
325
