3.5 Removing the Cover
Procedure
Step 1 Power off the compute node.
For details, see 3.1 Power-Off Procedure.
Step 2 Remove the compute node.
For details, see 3.3 Removing a CH121 V5.
Step 3 Place the compute node on the ESD workstation.
Step 4 Remove the cover.
1. Press the button on the cover and push the cover backwards as far as it will go. See (1)
and (2) in Figure 3-10.
2. Lift the chassis cover. See (3) in Figure 3-10.
Figure 3-10 Removing the cover
----End
3.6 Installing the Cover
Procedure
Step 1 Place the compute node on the ESD workstation.
Step 2 Take the spare part out of its ESD bag.
Step 3 Install the cover.
FusionServer Pro CH121 V5 Compute Node
User Guide
3 Basic Operations
Issue 06 (2019-08-10) Copyright © Huawei Technologies Co., Ltd. 35
