5486m570.fm Draft Document for Review October 18, 2004
144 IBM Eserver i5 and iSeries System Handbook
Main storage
All main storage on the Model 570 is feature main storage.
DVD-ROM or DVD-RAM
– #2640 DVD-ROM
– #5751 DVD-RAM
Internal disk units - 10k or 15k rpm only
– #4317 8.58 GB 10k RPM Disk Unit *
– #4318 17.54 GB 10k RPM Disk Unit *
– #4319 35.16 GB 10k RPM Disk Unit
– #4326 35.16 GB 15k RPM Disk Unit
– #4327 70.56 GB 15k RPM Disk Unit
One of the following load source specify codes is required:
– #0828 - #4317 Load Source specify *
– #0829 - #4318 Load Source Specify *
– #0830 - #4319 Load Source Specify
– #0834 - #4326 Load Source Specify
– #0835 - #4327 Load Source Specify
Disk protection specify codes (one must be specified)
– #0040 Mirrored System Disk Level
– #0041 RAID Protection - All
– #0042 Mirrored System IOP Level
– #0043 Mirrored System Bus Level
#0041 is the default for disk data protection.
Internal tape
The Model 570 only supports one slimline removable media slot for the
required #2640 DVD-ROM (default) or the #5751 DVD-RAM. The 9406 Model
570 does not support a removable magnetic media device in the base CEC. A
tower and associated support or an external tape or DVD-RAM device is
required.
System console attachment adapter
– #5540 System Console on Twinaxial Workstation IOA
• #4746 PCI Twinaxial IOA
– #5544 System Console on Operations Console
• #0367 Operations Console PCI Cable (attaches to #9793 or #9794)
– #5546 System Console on 100 Mbps Token Ring
• #2744 PCI 100 Mbps Token Ring IOA
• #0367 Operations Console PCI Cable
