#5078 PCI Expansion Unit
#5079 1.8 M I/O Tower
#5088 PCI-X Expansion Unit
#5094 PCI-X Expansion Tower
#5095 PCI-X Expansion Tower
#5294 1.8m I/O Tower
#5790 PCI Expansion Drawer
#8079 Optional Base 1.8 M I/O Rack
#8093 Optional 1.8 M I/O Rack
#8094 Optional 1.8 M I/O Rack
#9079 Base I/O Tower (PCI)
#9094 Base PCI I/O Enclosure
#9194 Base PCI-x Expansion Tower
#8294 Optional Base 1.8m rack
The #9844 Base PCI IOP is included with Models 520, 550, 570, 595, 825, 870,
and 890, and PCI-X I/O towers #0595, #5094, #5095, #5294, #8094, and #9094.
Placement considerations include:
Up to two #2844 PCI IOPs may be placed in the Model 270, 800, and 810
system units.
Up to five #2844 PCI IOPs may be placed in the Model 820 system unit.
Up to three #2844 PCI IOPs may be placed in the Model 825 system unit.
Up to three #2844 PCI IOPs may be placed in a #5075.
Up to two #2844 PCI IOPs may be placed in a #5095.
Up to four #2844 PCI IOPs may be placed in the Model 830, 840, 870, and
890 system units.
On the #0595/#5095 PCI-X Expansion Tower, a #9844 PCI IOP is included as
base. Up to two #2844 PCI IOPs may be added.
On the #5094 PCI-X Expansion Tower, a #9844 PCI IOP is included as base.
Up to five #2844 PCI IOPs may be added to a #5074/#5094.
On the #5078#5088/#0578/#0588 PCI Expansion Unit a #9844 PCI IOP is not
included in the base. Up to six #2844 PCI IOPs may be added.
On the #5294 1.8M I/O Tower two #9844 PCI IOPs are included as base. Up
to 10 #2844 PCI IOPs may be added to a #5079/#5294.
On the #5790 PCI ExpansionDrawer supports two #2844 PCI IOP with
blindswap cards. Two #5790 can be placed side by side in a rack with #7311
Dual I/O Unit Enclosure
The following IOAs are supported (driven) by the #2844/#9844 PCI IOP:
