D Filter shape set mode (continued)
5-16
5
FUNCTIONS FOR RECEIVE
HF SSB (600Hz – )
SHARP
Select the filter shape for SSB mode in HF bands. The set filter shape is automatically used only
when the IF filter is set to 600 Hz or wider.
SSB–D (600Hz – )
SHARP
Select the filter shape for SSB data mode in HF
bands.
The set filter shape is automatically used only
when the IF filter is set to 600 Hz or wider.
CW ( – 500Hz)
SHARP
Select the filter shape for CW mode in HF bands. The set filter shape is automatically used only
when the IF filter is set to 500 Hz or narrower.
CW (600Hz – )
SHARP
Select the filter shape for CW mode in HF bands. The set filter shape is automatically used only
when the IF filter is set to 600 Hz or wider.
50M SSB (600Hz – )
SOFT
Select the filter shape for SSB mode in 50 MHz
band.
The set filter shape is automatically used only
when the IF filter is set to 600 Hz or wider.
SSB–D (600Hz – )
SHARP
Select the filter shape for SSB data mode in 50 MHz
band.
The set filter shape is automatically used only
when the IF filter is set to 600 Hz or wider.
CW ( – 500Hz)
SHARP
Select the filter shape for CW mode in 50 MHz band. The set filter shape is automatically used only
when the IF filter is set to 500 Hz or narrower.
CW (600Hz – )
SHARP
Select the filter shape for CW mode in 50 MHz band. The set filter shape is automatically used only
when the IF filter is set to 600 Hz or wider.

Icom IC-7700 Specifications

General

Modes	SSB, CW, RTTY, AM, FM
Voltage	13.8 V DC ±15%
Output Power	200 W (SSB/CW/RTTY/FM)
Receiver Type	Superheterodyne
Display	7-inch color TFT LCD
Antenna Tuner	Automatic
Image Rejection Ratio	More than 70 dB
IF Frequencies	1st: 64.455 MHz, 2nd: 455 kHz
Selectivity	2.4 kHz (SSB), 500 Hz (CW)
Current Drain	2.5 A (receive)
