12-8
12
SET MODE
DATA2 MOD
MIC,ACC
Selects the desired connector(s) for modulation
input when data 2 mode (D2) is in use.
•MIC :Usethesignalsfrom[MIC].
•ACC :Usethesignalsfrom[ACC1](pin4).
•MIC,ACC :U se th e s ign als f rom [ MIC ] a nd
[ACC1] (pin 4). (default)
•S/PDIF :Usethesignalsfrom[S/PDIF].
•LAN :Usethesignalsfrom[LAN].
DATA3 MOD
MIC
Selects the desired connector(s) for modulation
input when data 3 mode (D3) is in use.
•MIC :Usethesignalsfrom[MIC].(default)
•ACC :Usethesignalsfrom[ACC1](pin4).
•MIC,ACC :U se th e s ign als f rom [ MIC ] a nd
[ACC1] (pin 4).
•S/PDIF :Usethesignalsfrom[S/PDIF].
•LAN :Usethesignalsfrom[LAN].
SEND Relay Type
MOS-FET
Selects the switching relay type for [RELAY] from
Reed and MOSFET.
Select the suitable relay type when connecting a
non-Icom linear amplifier.
•Reed : Use mechanical relay.
(16VDC/0.5Amaximum)
•MOS-FET:Usesemiconductortyperelay.
(250V/200mAmaximum: default)
External Meter Output
Auto
Selectsthedesireditemforanexternalmeterindi-
cation.
•Auto :Outputsthereceivingsignalstrength
level during receive, and outputs the
selected level (selected with [METER]),
during transmit. (default)
•S :Outputsthereceivingsignalstrength
level during receive.
•Po :Outputsthetransmittingpowerleveldur-
ing transmit.
•SWR :OutputstheVSWRlevelduringtransmit.
•ALC :OutputstheALClevelduringtransmit.
•COMP :Outputsthecompressionlevel during
transmit.
•Vd : Outputs the drain terminal voltage of the
final amplifier MOSFETs.
•Id : Outputs the drain current of the final am-
plifier MOSFETs.
External Meter Level
50
%
Setstheoutputlevelforanexternalmeterindication
within 0 to 100% range in 1% steps.
•Approximately2.5Vat50%(default)settingforfull-scale
indication. (4.7 kΩ impedance)
ACC set mode (continued)
