14
OPTIONS
14-4
MB-136 belt clip (for the Portable type transceiver)
D MB-136 contents
Belt clip
Base clip
D Attaching
1. Detach the battery pack, if attached. (p. 1-3)
2. Slide the base clip in the direction of the arrow
until the clip locks and makes a “click” sound.
3. Attach the battery pack to the transceiver. (p. 1-3)
Base clip
Battery pack
4. Clip the belt clip on your belt.
5. Insert the transceiver upsidedown into the belt clip
until the base clip is fully inserted in the groove.
6. Once the transceiver is locked in place, it swivels,
as shown to the right.
Once the transceiver is locked on place,
it will swivel 360 degrees.
