7
NXDN™ OPERATION
7-18
Site Lock function (For the Multi-site Trunking operation)
Y
ou can lock the transceiver to the currently registered
site. When this function is ON, the transceiver cancels
resuming a Roaming scan, and stays on the current
site, regardless of the error rate.
Hold down [Site Lock] for 1 second to turn the Site
Lock function ON or OFF
.
•
“
” is displayed when this function is turned ON.
