Appendix B Parameter Table
-
348
-
Appendix B Parameter Table
Function
Code
Name Setting Range Default Unit Property Page
Group F0: Basic parameters
F0-00 Control mode
0: Sensorless vector control (SVC)
1: Closed-loop vector control (CLVC)
2: Voltage/Frequency (V/F) control
1 -
★
P182
F0-01 Command source selection
0: Operation panel control
1: Distance control
1 -
★
F0-02
Running speed under
operation panel control
0.050 to F0-04 0.050 m/s
☆
P183
to
P184
F0-03 Maximum running speed 0.250 to F0-04 1.600 m/s
★
F0-04 Rated elevator speed 0.250 to 4.000 1.600 m/s
★
F0-05 Rated elevator load 300 to 9999 1000 kg
★
F0-06 Maximum frequency F1-04 to 99.00 50.00 Hz
★
F0-07 Carrier frequency 0.5 to 16.0 6.0 kHz
★
Group F1: Motor parameters
F1-00 Encoder type
0: SIN/COS encoder
1: UVW encoder
2: ABZ incremental encoder
3: Endat absolute encoder
0 -
★
P185
F1-01 Rated motor power 0.7 to 75.0
Model
dependent
kW
★
F1-02 Rated motor voltage 0 to 600
Model
dependent
V
★
F1-03 Rated motor current 0.00 to 655.00
Model
dependent
A
★
F1-04 Rated motor frequency 0.00 to F0-06
Model
dependent
Hz
★
F1-05 Rated motor speed 0 to 3000
Model
dependent
RPM
★
F1-06
Encoder initial angle
(synchronous motor)
0.0 to 359.9 0 °
★
F1-07
(synchronous motor)
0.0 to 359.9 0 °
★
F1-08
Synchronous motor wiring
mode
0 to 15 0 -
★
F1-09
(synchronous motor)
0.0 to 359.9 0 -
★
P186
F1-10 0 to 65535 0 -
★
F1-11 Auto-tuning mode
0: No operation
1: With-load auto-tuning
2: No-load auto-tuning
3: Shaft auto-tuning 1
4: Shaft auto-tuning 2
5: Static auto-tuning
0 -
★
F1-12 Encoder pulses per revolution 0 to 10000 2048 PPR
★
P187
F1-13
Encoder wire-breaking
detection time
0 to 10.0 2.1 s
★
F1-14
Stator resistance
(asynchronous motor)
0.000 to 30.000
Model
dependent
★
F1-15
Rotor resistance (asynchronous
motor)
0.000 to 30.000
Model
dependent
★
F1-16
Leakage inductance
(asynchronous motor)
0.00 to 300.00
Model
dependent
mH
★
F1-17
Mutual inductance
(asynchronous motor)
0.1 to 3000.0
Model
dependent
mH
★
F1-18
No-load current (asynchronous
motor)
0.01 to 300.00
Model
dependent
A
★
F1-19 Shaft Q inductance (torque) 0.00 to 650.00 3.00 mH
★
F1-20 Shaft D inductance (excitation) 0.00 to 650.00 3.00 mH
★
F1-21 0 to 65535 0 -
★
