LUBRICATING SYSTEM

114

OIL PUMP

DISASSEMBLY

1

5

4

3

2

Disassembly Steps

1. Oil pipe

2. Strainer case

3. Pump cover

4. Vane

▲ 5. Pump body with rotor and pinion

051ET001
