ENGINE ASSEMBLY ( 2 )

Oil Seal Installation

1. Apply a coat of engine oil to the oil seal lip circum-

ference.

2. Use the oil seal installer and the installer grip to

insert the oil seal 1 mm (0.039 in) into the front por-

tion of the timing gear case.

Oil Seal Installer: 5-8840-2061-0
