ENGINE ASSEMBLY ( 1 )

45

CAMSHAFT, CAMSHAFT TIMING GEAR, AND THRUST PLATE

1

2

3

4

Disassembly Steps

▲ 1. Camshaft timing gear

▲ 2. Thrust plate

3. Feather key

4. Camshaft
