TROUBLESHOOTING

198

Exhaust manifold

Loosely connected exhaust mani-

fold and/or glow plugs

Tighten the exhaust manifold

connections

Cylinder head gasket Damaged cylinder head gasket Replace the cylinder head gasket

Loose fan belt Readjust the fan belt tension

Loose cooling fan Retighten the cooling fan

Water pump bearing

Cooling fan

Fan belt

Worn or damaged water pump

bearing

Replace the water pump bearing

Alternator or vacuum pump

Defective alternator or vacuum

pump

Repair or replace the alternator

or the vacuum pump

Valve clearance

Valve clearance improperly

adjusted

Adjust the valve clearance

NG NG

Continued from the previous page

10. ABNORMAL ENGINE NOISE

2. Gas Leakage Noise

Checkpoint Trouble Cause Countermeasure

3. Continuous Noise

Table of Contents3
