Isuzu A-4JB1 Repair Manual

MAINTENANCE
28
ENGINE REPAIR KIT
All of the numbered parts listed below are included in the Engine Repair Kit.
The gaskets marked with an asterisk (*) are also included in the Top Overhaul Kit.
3
15
13
12
2
17
18
14
1
11
7
16
8
9
4
19
6
10
19
20
19
5
* 1. Cylinder head gasket
* 2. Cylinder head cover gasket
* 3. Head cover cap nut gasket
4. Drain cock gasket
5. Crankshaft rear oil seal
6. Gear case gasket
7. Gear case cover gasket
8. Oil pan drain plug gasket
9. Oil pan gasket
10. Oil filter gasket
11. Water pump gasket
12. Water outlet pipe gasket
* 13. Thermostat housing gasket
* 14. Intake manifold gasket
* 15. Exhaust manifold gasket
16. Crankshaft front oil seal
* 17. Nozzle holder O-ring
* 18. Nozzle holder gasket
19. Joint bolt gasket
20. Vacuum pump pipe gasket
