ENGINE ASSEMBLY ( 1 )
Important Operations
1. Rocker Arm Shaft Snap Ring
2. Rocker Arm
3. Rocker Arm Shaft Bracket
1) Use a pair of snap ring pliers to remove the
snap rings.
2) Remove the rocker arms.
3) Remove the rocker arm shaft bracket.
If the rocker arms and rocker arm shaft brackets
are to be reinstalled, mark their installation
positions by tagging each rocker arm and rocker
arm shaft bracket with the cylinder number from
which it was removed.
40
To Next Page
