– 160 –
9-6. Simple lock of the screen
Simple lock is activated by keeping
❶
held pressed for one second on the sewing
screen.
Pictograph display
❶
will be as shown be-
low:
: Simple lock is enabled
: Simple lock is disabled
<Sewing screen>
time. (With memory switch U402)
Refer to
"5-5. List of memory switch data"p.77
for details.
Once the simple lock is enabled, operation of the buttons displayed on the screen is disabled, thereby
preventing maloperation.
9-7. Version information
<Mode screen>
1) Press
❶
.
The "mode screen" is displayed.
2) Select the "7. Version".
The "version information screen" is
displayed.
3) The screen returns to the previous
screen by pressing
❷
.
When
❸
is pressed, the "com-
munication version information screen"
is displayed.
<Version information screen>
<Communication version information screen>
4) When
❹
is pressed on the "com-
munication version information screen",
the screen returns to the "version infor-
mation screen".
❶
❶
❹
❷
❸
To Next Page
