– 4 –
2-3.
Installation of the sewing machine
Sheet B
❹
25 mm
❺
19 mm
Sheet A
❷
❹
❸
❸
❺
❺
❻
❼
❶
❽
1) Attaching the hinge seats and the support
rubbers of the machine head
Fix accessory hinge seat
❶
supplied with
the unit on the table with wood screw
❼
and washer
❽
while placing sheet plate
❻
between the hinge seat and the table as
Fix machine head support rubbers
❷
and
❸
on the table with nails while putting
sheets
A
(standard: 3 pieces) and sheet
B
(standard: 1 piece) under the machine
head support rubbers.
Use nail
❺
for sheet
B
and nail
❹
for
sheets
A
.
support rubbers
❸
; i.e., the rubber for the
right and that for the left. Be sure to check
the types of the support rubbers before
Sheet A (eight pieces) and sheet B (four pieces) are supplied with the machine as acces-
sories.
For the sheet A, three sheets are to be used as standard for each mounting position. For
the sheet B, one sheet is to be used as standard. (The state shown in the left gure) The
sheets A and B are used for adjusting the height of the top surface of the bed. Use one
more sheet to increase the height, or use only one sheet to decrease it.
Be sure to use a short nail
❺
for sheet B. If long nail
❹
is used, the nail tip can penetrate
the table giving rise to a risk of injury.
2) Attaching the oil pan
Fix the oil pan
❾
supplied with the machine
on the table by tightening ten wood screws.
Operator’s side
Table
❾
Align
Align
To Next Page
