Installing a Cable-Management Bracket on ERX-7xx Models
!
97
Chapter
9: Maintaining E-series Routers
Figure 51: Attaching a cable management bracket
Perforated area
Front of
ERX-7xx model
Mount here for wider X.21/V
.35 cables
Mount in this area for smaller cables
g013767
