E-series Hardware Guide
66 ! Cabling I/O Modules
Figure 33: ERX-310 router, rear view (AC model)
Cabling I/O Modules
The following section illustrates the common connector types used with E-series I/O
modules. For information about the connectors on the different line modules, see
Chapter 12, Module Specifications.
BNC Connectors
Figure 34: I/O module with BNCs
Ground
AC power input A
with switch
AC power input B
with switch
POWER A POWER B
100-240V ~ 5A
50/60 Hz
|
O
|
O
g013754
CT3
I/O
Port 0
Port 1
TX
RX
RX
TX
g013755
