Keithley 2600a series User Manual

In this section:
Topic Page
Overview............................................................................................. 6-2
Range.................................................................................................. 6-2
Available ranges............................................................................ 6-2
Maximum source values and readings.......................................... 6-3
Ranging limitations........................................................................ 6-3
Manual ranging ............................................................................. 6-3
Auto ranging.................................................................................. 6-3
Low range limits ............................................................................ 6-3
Range considerations ................................................................... 6-4
Range programming ..................................................................... 6-4
Digits................................................................................................... 6-6
Setting display resolution .............................................................. 6-6
Remote digits programming .......................................................... 6-6
Speed.................................................................................................. 6-6
Setting speed ................................................................................ 6-7
Remote speed programming......................................................... 6-7
Rel ...................................................................................................... 6-8
Front panel rel ............................................................................... 6-8
Remote rel programming .............................................................. 6-9
Filters.................................................................................................. 6-9
Filter types..................................................................................... 6-9
Front panel filter control................................................................. 6-10
Remote filter programming............................................................ 6-12
Section 6
Range, Digits, Speed, Rel, and Filters

Keithley 2600a series Specifications

General

Category	Source Measure Unit (SMU)
Model	2600A Series
Type	Precision SourceMeter
Voltage Range	±200V
Current Range	±10fA to ±10A (depending on model)
DC Current	±10A
Pulse Current	±100A
Maximum Power	20W to 200W (depending on model)
Power per Channel	20W
Accuracy	0.012% basic
Interface	GPIB, USB, Ethernet
Power Supply	100V to 240V, 50Hz to 60Hz
Weight (1-channel)	4.5kg
Channels	1 or 2
Dimensions (1-channel)	89 mm high x 214 mm wide x 429 mm deep (3.5 in x 8.4 in x 16.9 in)
Dimensions (2-channel)	89 mm high x 214 mm wide x 429 mm deep (3.5 in x 8.4 in x 16.9 in)
