1-18 Return to Section Topics 2600AS-901-01 Rev. B / September 2008
Section 1: Getting Started Series 2600A System SourceMeter® Instruments Reference Manual
Menu navigation
When the Series 2600A is not in the edit mode (the EDIT indicator is not illuminated), the editing
controls are used to navigate the Main and Configuration menus to make selections and/or set
values (see
Menu navigation for more information). After entering a menu structure, use the
editing keys as follows:
Selecting menu items
•Use the CURSOR arrow keys to select a menu or an option.
• Press the ENTER key to select an item or menu option.
• Rotate the navigation wheel (clockwise or counter-clockwise) to select a value.
•Use the EXIT key to cancel changes or to return to the main menu.
NOTE You can use the navigation wheel to select items from the menu or a
submenu.
Setting a value
There are two ways to adjust a value: Value adjust or numeric entry. To use the keypad, the
keypad feature must be enabled. Both methods use the following editing techniques:
• To set a value to zero, press the 0000 numeric entry key.
• To toggle the polarity of a value, press the +/– numeric entry key.
Value adjust method
1. Use the CURSOR arrow keys to move the cursor to the value that you want to edit.
2. Push the navigation wheel or ENTER to enter edit mode. The EDIT indicator is illuminated.
3. Rotate the navigation wheel to set the appropriate value.
4. Press ENTER to select the value. Press EXIT to cancel the change.
Numeric entry method
1. Use the CURSOR arrow keys to move the cursor to the value that you want to edit.
2. Press the number entry key (0 to 9). The cursor moves to the next value on the right.
3. Repeat Step 2. as required to set the desired values.
4. Press ENTER to select the value.
5. (Optional) Press EXIT the cancel change and to return to the main menu.
NOTE The numeric entry method may only be used if the numeric keypad is
enabled.
